Montura 250 mm Rosca 2"

Montura italiana marca Irritec

Ideal para tuberia o manguera con diámetro exterior 250mm

Disponible con salida lateral en rosca hembra de 2"

MONTURAS CON ANILLO DE REFUERZO ME

DESCRIPCIÓN

MONTURA 75 X1 1/2" ITALIA

MONTURA 75 X2"
MONTURA 90 X 2"
MONTURA 110 X 2"
MONTURA 110 X 3"
MONTURA 140 X2"
MONTURA 140 X 3"
MONTURA 160 X 1"
MONTURA 160 X 2"
MONTURA 160 X 3"
MONTURA 200 X 2"
MONTURA 200 X 3"

ITALIA
ITALIA
ITALIA
ITALIA
ITALIA
ITALIA
ITALIA
ITALIA
ITALIA
ITALIA
ITALIA

ICO

PRESIÓN
NOMINAL

10bar
6bar
6bar
10bar
6bar
10 bar
6bar
10 bar
10 bar
6bar
6bar
6bar

Fittings and valves high pressure
Clamp saddies

CLAMP SADDLES
The Clamp Saddle line has been designed for side outputs on Polyethylene pipes
(PE) anditis available in the following range of sizes:

* ltem 103/104 with single or double output. They have diameters for the coupling with
2 20 to 9 315mm pipes and threaded outputs (1/2” to 3”), provided with 2, 4 and 6
bolts according to the diameters.

* ltem 105/106 with single or double output. They have diameters for the coupling with
2 20 to 9 315mm pipes and threaded outputs (1/2” to 4”), provided with 2, 4 and 6
bolts according to the diameters, and reinforcing ring on threads.

Materials [3 —
Parts Material Colour DD e
y Black mastered polypropylene copolymer with a FT — -

and lid (A) high level of stabilization to UV e o
Gasket (B) Acrylonitrile elastomeric rubber (NBR) 70 Shore A black -

Reinforcing ring (C) Stainless steel AISI 430 for model 105-106 anly - E
Nuts and bolts in zinc-plated steel hexagonal head Zinc -

Bolts (D) screws threaded UNI 5739 chromate
Nuts according to standard UNI 5588 steel (7
[0.3]

Sanitary Prescriptions
The Clamp Sadde line is suitable for conveying food fluids because its materials comply with the applicable national and international
standards.

Lab tests
The high quality of the products is guaranteed by periodical quality audits, through strict lab tests, under the most severe testing conditions.

Working Pressures
The Clamp Sadde line allows a maximum working pressure (PN —- PFA*) from 4 to 16 bars, at a temperature of 20 “C. See, in detail, the
PN - PFA* values reported in the tables for every single product.

Reference Standards

* PE pipes: UNI 7990, DIN 8074, UNI EN 12201

* Threads: UNI ISO 7/1 , UNI ISO 228/1, ANSI ASME B1-20.1
* International standard: 1SO 13460

Racores y válvulas alta presión
Abrazadera tristes

SILLAS DE ABRAZADERA
La línea Clamp Saddle ha sido diseñada para salidas laterales en tuberías de Polietileno
(PE) anditis disponible en la siguiente gama de tamaños:

* ltem 103/104 con salida simple o doble. Tienen diá
