Filtro anillos PEQ 1 1/2" - FLF

Filtro anillos Pequeño 

Filtros de anillos 120 MESH

Modelos FLF

Disponible en 1 1/2" y 2"

FLE
FLF
TECHNICAL CHARACTERISTICS
Pol ypropy lene f i l ter
Clos ing s y s tem: wi th threaded cover
Max . pres sure: 8 bar at 20°C
Nominal f low rate: 1 0 m3/ h
Fi l ter ing car t r idge: s tainles s s teel s c reen
polyester screen (220 cm2) - Disks (260 cm2)
Car t r idge diameter 5 8 mm
Car t r idge length 156 mm
Avai lable connec t ions : 1 1/4” - 1 1/2” (BSP-NPT)
TECHNICAL CHARACTERISTICS
Pol ypropy lene f i l ter
Clos ing s y s tem: wi th threaded cover
Max . pres sure: 8 bar at 20°C
Nominal f low rate: 2 0 m3/ h
Fi l ter ing car t r idge: s tainles s s teel s c reen
polyester scre (450 cm2) - Disks (500 cm2)
Car t r idge diameter 8 6 mm
Car t r idge length 198 mm
Avai lable connec t ions 1 1/2” - 2” (BSP-NPT)
5 10 15 20 25 30
0,0
0,1
0,2
0,3
0,4
0,5
0,6
1 1/2"
2"
0
0,0
0,1
0,2
0,3
0,4
0,5
0,6
2 4 6 8 10 12 14 16
1 1/4"
1 1/2"
Diagrams obtained during lab tests at room temperature, with fresh water and free discharge,
and a 120 mesh filter.
Diagrams obtained during lab tests at room temperature, with fresh water and free discharge,
on a 120 mesh filter.
Flow rate [m3/h]
Pressure head loss [bar]
Flow rate [m3/h]
Pressure drop [bar]

O ao

MESH FILTRO FILTRADO EN mm
8 MESH 3" METÁLICO 3mm
20 MESH MALLA 1.25 mm
50 MESH MALLA 0.50 mm
120 MESH ANILLOS ROJOS 0.25 mm

MESH = 4t DE AGUJEROS POR PULGADA LINEAL

TABLA TÉCNICA DE FILTROS



pea pa NN
FLD 3/4* 2.5 m3/h 2 mca
FLE 11/4* 5 m3/h 1.5 mca
11/2* 8m3/h 1.5 mca

rd 2" PEQUEÑO ANILLOS 10 m3/h 1.5 mca
2" PEQUEÑO MALLA 20 MESH 10 m3/h 1.5 mca

2" PEQUEÑO MALLA 50 MESH 10 m3/h 1.5 mca

FLG 2" MEDIO OBLICUO 20 m3/h Tmca
FLH 3" GRANDE OBLICUO 30 m3/h Tmca

NOTA: Presión máxima 8 bar (120 psi)
